Product Overview

Locknetics, MG600 Electromagnetic Lock 600lbs

The MG Series of surface mount electromagnetic locks provides a cost competitive, slim profile and dependable solution for a variety of applications.

Features

Bi-colored LED bond sensor included
Removable PCB for easy installation
Built-in voltage spike suppressor
Field Selectable 12/24 VDC

Model

MG600 - standard 600lb model
MG600DT - monitored 600lb model with Door Status Monitor and Adjustable Re-lock Timer (0-90sec adjustable)

Specification

UL10C
UL294

Dimensions

Lock: 9-7/8 inches x 1-7/8 inches x 1-1/16 inches
Armature: 7-5/16 inches x 1-1/2 inches x 1/2 inches

Options

MZBK600 - Z Bracket kit for inswing doors *sold separately

Also Known As:

LOC100MG600, Locknetics MG600

Finish:

Stainless Steel

Manufacturer:

Locknetics

Model Number:

MG600

Power Requirements:

24VDC/12VDC

UPC Code:

043156646173

Datasheet PDF

User Guide PDF

1 Question asked on Locknetics, MG600 Electromagnetic Lock 600lbs • Ask a Question

Q John Mondo • 07/08/2024, 2:33:11 PM Is there an app to unlock this?

A 07/11/2024, 11:29:40 AM We offer a variety of Electronic Control options that can be used to unlock this maglock. For a complete PIN/Prox/APP solution, please see the DoorBird A1121 Access Control Station. To go over any additional questions regarding this maglock or the DoorBird A1121 please give us a call at 1-866-500-5625
