N-Series Software Not Compatible with T-Series Controllers

Product Overview

Access control with built in TCP/IP Ethernet interface. The ACP series from Cobra Controls allows you to connect an unlimited number of 1, 2 or 4 door panels to your network for complete system expansion. Cobra controllers use NON-PROPRIETARY readers and inputs based on the industry standard Wiegand format. ACP-N Series Controllers are not compatible with ACP-T Series Controllers.

Models

ACP-4N (4-Door Controller: 2amp)
ACP-2N (2-Door Controller: 2amp)
ACP-1N (1-Door Controller: 2amp)
ACP-4NF (4-Door Controller: 4amp)
ACP-2NF (2-Door Controller: 4amp)
ACP-1NF (1-Door Controller: 4amp)

Features

Easily add or remove card holders with only a few mouse clicks
255 time zones with start and stop dates
Individual door sensor/monitoring inputs for each door
Individual request to exit RTE inputs for each door
Lost card registry with simple reissue feature
Unlimited departments and sections
Unlimited number of control panels and doors on same system
Audit trail customizable by date, department, user, and/or by door. Report layout also flexible. Save as Excel spreadsheet, print, or view.
Industry standard 26 bit Wiegand interface to work with any combination of Card readers, keypads, fingerprint reader, bar-code reader, etc. with Wiegand output.
Real time monitoring through software for alarms, duress, invalid card reads, door propped, and door forced events.
Anti-pass back
Storage capacity: 20,000 users and 100,000 events

Real Time Monitoring

The Cobra Controls .net Access Control Software also offers a powerful real time monitoring and management interface. Watch as the computer scans doors and reacts to real time events.
Note: Live connection to controllers not required for doors to operate - needed only for live interaction. Features of real time monitoring screen:
Check command performs status and diagnostics on selected doors and their controllers. Setting time synchronizes controllers to the computer for timing. Upload and download from this interface to update both the controller with correct access privileges and to receive latest auditing information. A real-time download option keeps you up to the second with event monitoring.
Remote locking and unlocking of any one or all doors is a simple mouse click. You can "lock down" or lock open any one or multiple doors. Momentary unlock a door and then it will go back to normal access state. Reset alarms via mouse.

Specifications

12VDC 2amp Linear Power Supply in locking metal enclosure with outputs for control panel and electronic locks included
16.5 VAC Transformer included
Locking Metal Enclosure included 12.0 inch x 13.0 inch 3.9 inch

ACP-N Series Computerized Access Control

Function Introduction
Conventional Function	Offline operation; real time supervision; photo display; mass storage; flexible user privilege setup; remote unlocking; multi-user supervision; quick setting; convenient checking and query; revisable and printable report form; report form; report can be exported to excel file; card+password unlocking; alarm for long time unclosing; alarm for invalid card swiping; first card unlocking; alarm for illegal break in; unlocking at definite time; e-map etc.
Professional function	For professional users such as bank, cash house, telecom station, power supply station, prison and police station: interface locking; intimidation alarm; integrated fire control; anti-passback and anti-tail; interlocking; multi-card unlocking; emergency double locking; in door population checking; unlocking based on internal and external validation.
all-in-one-card management system	normal shift and multi-shifts time attendance management system; fixed ration dining management system; meeting attendance management system; online patrol management system and security alarm management system.
Parameter
Communication	TCP/IP 10M/100M adaptive
English Software supportable database	Access and SQL
Description	Control 1, 2 or 4 door, get in and out door by swiping card, or get in by swiping card and get out door by button
Power Supply	12VDC, 2amp supply standard. (12VDC, 4amp supply with fire panel tie in available)
Power Consumption of Circuit Board	Less than 100mA
Input Format of Reader	Wiegand 26 (All card reader with compatible protocol, such as Motorola , HIDÂ® (H10301), EM , Mifare one etc.)
Quantity of Readers	2 readers per door
Door Controlled	Boards available for 1,2 or 4 door.
Door opening time extending setting	1-600 seconds (adjustable)
Max Quantity of controller	N = No limit
	Remark: N denotes quantity of computer serial port or quantity of 485 hub port, support 256pcs ports
Operation Temperature	minus 40 - plus 70
Operation Humidity	10-90 % RH - No Condensation
Quantity of users	20,000 Users
Quantity of Event Buffers (offline)	100,000 event buffers
Power interruption protection measure	High Speed Memory, Records never lose
Max Distance from Reader to Controller	100m (suggestion distance 80m)
Max Distance between Controllers	RS232: Communication Distance less than 13m, suggestion distance is 3m or less
	RS485: bus line max length 1200m, suggestion length 1000m or less, if expansion device added, the distance could be 3000m
	TCP/IP: Depends on net coverage area
Collocations	PCB board, case, power, power line, serial port communication line, software, manual, certificate, key(2pcs), carton
Alarm for long time door open, illegal break in, intimidate	Yes
Fire and alarm linkage	If no connection with the expansion board, only has software interface alarm, and drive the computer speaker. If connected with expansion board, is able to alarm by hardware, if connected with strengthened expansion board, then is able to Security alarm
Compulsive open and close door at long time	Yes
Open door in remote distance	Yes
Inter lock	Yes
Anti pass back and tail	Yes
Multi-card open door	Yes
Open long time at specified time	Yes
Electronic map	Yes
Urgency locking	Yes
First card unlocking	Yes
Unlock based on internal and external validation	Yes
Keypad (card+password, super password)	Yes
