Locknetics, EMS-100 Exit Motion Sensor
Processing...

20% Off MSRP

Locknetics, EMS-100 Exit Motion Sensor

$128.00 $160.00

Overview

The EMS-100 is designed for use on request-to-exit applications with maglocks and electric strikes.

The key advantages of the EMS-100 are fast detection, adjustable sensing fields, and no false detection from inanimate objects.

More Info +


Qty

Product Details

Product Overview

Locknetics, EMS-100 Exit Motion Sensor

The EMS-100 is designed for use on request-to-exit applications with maglocks and electric strikes.

This sensor is not an automatic door activation sensor. It is a request to exit sensor used to release a lock.The unit is a passive infrared detector that uses digital signature analysis for activation.

The EMS-100 is not recommended for activation on pedestrian automatic doors because the passive infrared technology recognizes temperature changes (i.e. body temperature) for detection. As such, the EMS-100 will not recognize motion associated with inanimate objects such as hospital beds, gurneys, shopping carts, etc.

The key advantages of the EMS-100 are fast detection, adjustable sensing fields, and no false detection from inanimate objects.

Features

  • Passive infrared with microprocessor
  • 15 Fresnel lenses with full independent masking possibilities
  • 9 feet of four-conductor cable with 5-pin connector
  • Includes ceiling and surface mount adapters

Model

  • EMS-100, EMS100 - Exit Motion Sensor, Ceiling Or Surface Mount

Specification

  • 12/24 VDC input power
  • SPDT Relay
  • 10 mA (20mA if the relay output is activated)
  • Operating temp: -22 degrees F to 140 degrees F

Dimensions

  • 4 inches L (100 mm.) x 1 inch H (25 mm.) x 1.8 inches W (45 mm.)

Options

  • (none)
Finish
Black
Manufacturer
Locknetics
Model Number
EMS-100
Power Requirements
24VDC/12VDC
Usage
Interior Use
1 Question asked on Locknetics, EMS-100 Exit Motion Sensor



Q Shawn • 02/04/2020, 1:15:51 PM Does this allow push button Access?
A 02/05/2020, 11:27:20 AM The EMS-100 is a Request to Exit motion sensor, designed to cut power to a maglock allowing exit. A push button can be used in addition to this sensor but would have to be purchased separately. For help designing a complete system please give us a call at 1-866-500-5625
