DynaLock, 6451 Series Exit Sensor Bar

Product Overview

The non-latching 6451 Exit Sensor Bar offers immediate (no prior knowledge) egress by pushing on the bar at any point, with 15 Lbs. or less pressure. A light touch is all that is required to activate one or both internal optical sensors designed to detect an exit attempt. A built-in mechanical switch is also included as a redundant back-up release. Dual sensors, fail-safe electronics and successful testing in excess of one million cycles offer the user unparalleled reliability and low maintenance costs.

Installation is simple. Complicated tune-in procedure and frequent call-backs for readjustment are not required.

Standard Features

• Optical sensing electronics, no moving parts to wear out.
• Built-in redundant mechanical switch for back-up release
• Bar may be field cut
• Bar may be activated by anything - human touch, briefcase, cane, wheelchair etc
• Ideal for ADA compliant installations
• 12/24 VAC/VDC operation
• Weather resistant electronics
• All-metal construction - entire bar, and endcaps is made of aircraft grade aluminum
• High resistance to abuse and vandalism
• Unit is non-handed -suitable for LHR or RHR doors.
• Armored power transfer cord included
• Made in the USA
• Lifetime Warranty

Technical Specifications

• Bar Length:
• 36” Door = 34” Overall Length
• 42” Door = 40” Overall Length **special order
• 48” Door = 46” Overall Length **special order
• Bar Width: 2-7/16 inch
• Bar Projection: 2-3/8 inch
• Operating Force: 15lbs Maximum
• Operating Temp: -10° F to 120° F
• Life Expectancy: 1,000,000 Cycles Minimum
• Construction: Aluminum
• Current Draw: 100 mA Maximum

Models

• 6451-36 US28 base model for 36 inch door, US28 Satin Aluminum finish

Finishes

• US28 Satin Aluminum with clear anodize

Specifications

• Model: 6451 (6451-36 US28)
• Also known as: DYN100645136US28, 645136US28, DY-645136US2
• Manufacturer: DynaLock
• Type: Non-latching exit sensor bar (optical sensors with redundant mechanical switch)
• Operating force: 15 lb or less
• Voltage: 12/24 VAC/VDC
• Current draw: 100 mA maximum
• Bar length: 36 inch door = 34 inch overall; 42 inch door = 40 inch overall (special order); 48 inch door = 46 inch overall (special order)
• Bar width: 2-7/16 inches
• Bar projection: 2-3/8 inches
• Operating temperature: -10°F to 120°F
• Life expectancy: 1,000,000 cycles minimum
• Construction: Aircraft grade aluminum, all metal
• Finish: US28 satin aluminum, clear anodize
• Handing: Non-handed
• Status monitor: Optional
• Origin: Made in the USA
• UPC: 789957619441
• Warranty: Lifetime
