General Description

The Rosslare EX-06 is a heavy duty, non-sparking, non-magnetic, corrosion resistant, illuminated, anti-vandal, mullion sized timed analog switch, designed for both indoor and outdoor use. It features solid state Piezoelectric Switch Technology generating a dry contact N.O. and N.C relay pulse simply by the touch of a finger, with no physical movement or moving parts. Select brilliant red, vibrant green or no illumination as a status indicator with the jumper selectable illumination status feature.

Main Features

Advanced Soft Touch Piezoelectric Switch
New weatherproof design is water and dust proof, grease, oil and other chemical solvent repellent
Circuit assembly encapsulation
Vandal resistant, stainless steel mounting plate and tactile button with no moving parts
Mounting Method Single Gang: Mounts directly to a US gang switchbox
Backed by Rosslare’s International Guarantee and service with ISO9001 (Certified TUV Rhineland) level business and manufacturing operations
Non-sparking, non-magnetic, corrosion resistant
Light ring status indicator and accidental activation hindrance
Adjustable output and LED indication time of 1 to 60 seconds
Output and indication Toggle option
Jumper Selectable Illumination Status: Red, Green, or No Illumination
One Relay with two 2.0 Amp outputs for separate application wiring: N.O. and N.C.

Applications

Mines
Hospitals
Gates
Oil Rigs & Refineries
Military
Heavy Machinery
Mechanical Operation Panels
Electronic Access Control Systems

Specifications

Switch Type: Piezoelectric, solid state, no moving parts; timed analog switch
Operating Voltage: 10 to 24 VDC
Current: 15 mA standby; 140 mA maximum (at 24 VDC)
Relay: One relay with separate N.O. and N.C. outputs, 2 A each
Output and LED Time: Adjustable, 1 to 60 seconds; toggle option
Illumination: Red, green or none (jumper selectable)
Mounting: Single gang, mounts directly to a US gang switchbox; optional MP-06 surface mount metal backbox (sold separately)
Operating Temperature: -35°C to 66°C (-31°F to 151°F)
Humidity: 0 to 85%, non-condensing
Ingress Protection: IP65; indoor and outdoor
Dimensions: 4.5 x 2.75 x 1.25 inches (11.4 x 7 x 3.2 cm)
Weight: 8.395 oz (238 g)
Material: Stainless steel plate and button
Listing: UL 294 (certificate 20130801-BP9264)
Warranty: 5-year limited
