MPT17-12 Multi-Purpose Digital Timer, 12VDC
$59.00
Product Overview
The MPT17-12 is a panel mount digital timers with a form relay capable of 16A@ 30VDC. The MPT17-12 has an internal battery for memory backup of programming in the event of power failure. The MPT17-12 is designed with 17 ON/OFF events per day and 15 combinations of daily programs for the best flexibility to the user.
Specifications
- Model: MPT17-12, multi-purpose digital timer, 12 VDC (replaces ETM-17-12)
- Operating voltage: 12 VDC
- Output: Form C relay, 16 A at 30 VDC
- Programming: 17 ON/OFF events per day; 15 combinations of daily programs
- Memory backup: internal battery
- Mounting: panel mount
- Manual button for temporary override
Application
The MPT17-12 can automatically and reliably control electrified locks and magnets, automatic overhead and pedestrian doors, or control lighting or energy management devices.
Also Known As:
MPT17-12 Digital Timer, multi-purpose digital timer, TM619-4Finish:
WhiteManufacturer:
Cobra ControlsModel Number:
MPT17-12Power Requirements:
12VDC
1 Question asked on MPT17-12 Multi-Purpose Digital Timer, 12VDC •
Q
James Culpepper • 09/22/2024, 3:35:49 AM
Is this mpt17 timer compatible with the electric strike bathroom kit?
A
09/24/2024, 12:06:21 PM
Yes, the MPT17 digital timer can be added into the majority of our electric lock packages including the Electric Strike Bathroom kit. For any additional questions on this product or to get a custom kit put together please give us a call direct at 1-866-500-5625
