Arrow RL12SR STOREROOM Function Cylindrical Lockset, Grade 2

Product Overview

The RL Series has been enhanced to offer removable through bolts and uses an ADA acceptable door handle for easy to use one handed egress. Perfect for light commercial applications including office buildings, waiting rooms and most medium traffic areas.

Specifications

• Function: Storeroom
• Grade: ANSI A156.2, Series 4000, Grade 2
• Construction: Cold rolled steel with zinc dichromate finish for corrosion resistance. Requires standard 2-1/8 inch (53.97mm) bore through door.
• Backset: 2-3/8 inch (60.31mm) or 2-3/4 inch (69.85mm)
• Door Thickness: Fits 1-3/8 inch (34.93mm) to 1-3/4 inch (44.45mm) doors standard.
• Latch: Brass 1/2 inch (12.7mm) throw, UL Listed, guarded latchbolt on all locking functions
• Latch Front: 1 inch x 2-1/4 inch (25.40mm x 57.15mm) for 2-3/8 inch backset (60.32.mm) or 1-1/8 inch x 2-1/4 inch for 2-3/4 inch (69.85mm) backset.
• Exposed Trim: RL Levers are pressure cast zinc measuring 4-3/4 inch (120.65mm) in length. RL Roses are wrought brass 3-3/8 inch (85.73mm) diameter. Total projection from face of door is 2-1/2 inch (63.5mm).
• Strike: 4-7/8 inch ANSI (123.83mm), 2-3/4 inch (69.85mm) T strike, or 2-1/4 inch (57.15mm) full lip strike.
• Lever style: Sierra (SR)
• Cylinder: solid brass, 6 pin, keyed different; Arrow "A" or Schlage C keyway; optional prep for small format interchangeable core
• Keys: 2 brass keys
• Handing: Non-handed
• Thru-bolts: Removable thru-bolts standard on RL Series
• Listing: UL listed for use on 3-hour, A label single swinging doors
• Compliance: RL levers conform to ADA requirements; ICC A117.1 compliant; ANSI/BHMA A156.41 (2020)
• Door types: hollow metal, wood
• Warranty: 5 year limited
• Common finishes: US3 / 605 bright brass; US10 / 612 satin bronze; US26D / 626 satin chrome
