602RFA 1A 12 24VDC POWER SUPPLY UL294 Large Cabinet

30% Off MSRP

602RFA 1A 12 24VDC POWER SUPPLY UL294 Large Cabinet

$345.80 $494.00


SDC 602RFA 602 Series 1 Amp, 12/24VDC Class 2 DC Power Supply/Charger with 16 inch x 14 inch x 6 1/2 inch Large Cabinet. Batteries not included.

More Info +

Door Controls:


Product Details

Product Overview

All SDC power supplies are equipped with a high performance transformer and highly reliable electronic components. Filtering and output voltage regulation provide protection and ensure the longevity of all system components. With the addition of SDC programmable controllers or relay modules, the user-friendly modular designs ensure versatility, interface capability and easy installation of electric locking devices, access controls and related safety equipment.


  • Selectable 12/24 VDC output, 1A
  • Auto resetting output circuit protection
  • Low Battery Disconnect, helps to prevent deep discharge and battery destruction.
  • Fire Alarm/Emergency Release Input, provides simultaneous release of all fail safe locks
  • ALVY - Access Control Systems Unit (UL294)
  • APHV - Power Supplies for Use with Burglar-Alarm Systems
  • Made in the USA


  • 602RFA 1 AMP Power Supply (large Cabinet)
  • 602RFAXUR-1 1 AMP Power Supply (large Cabinet) UR-1 Microprocessor Controller, Two Relays
  • 602RFAXUR2-4 1 AMP Power Supply (large Cabinet) UR2-4 Microprocessor Controller, Four Relays
  • 602RFAXUR4-8 1 AMP Power Supply (large Cabinet) UR4-8 Microprocessor Controller, Eight Relays


  • XPC - 6 foot plug-in power cord. Eliminates the need for AC conduit.

Electrical Specifications

  • Input: 115VAC, 600 mA, 50/60Hz direct wire (optional PC 6 foot plug-in power cord available)

Mechanical Specifications

  • Dimensions: 16 inches L x 14 inches W x 6.50 inches D, 20 GA
  • Weight: 9.8 lbs

* batteries sold separately.

Also Known As
SDC Security
Manufacturer Warranty
5 Year
UPC Code
