433MHZ Wall Mounted Touch Transmitter, Single Channel, IP55
$75.88
Product Overview
The wall-mounted TRAKEYFREE2 transmitter is a special radio transmitter operating at 433.92 MHz in AM/ASK modulation.
It is mainly composed by a capacitive touch sensitive circuit and by a radio transmitter. It can be used to operate gates, doors or garage doors or any device with the corresponding compatible 433 MHz receivers. (sold separately)
Technical Specifications
- Frequency: 433.92 MHZ
- Channels: 1
- Enclosure Grade: IP55 for Indoor or outdoor use
- Enclosure Color: White
- Wireless/Battery Operated
- Battery Type: ER14505 Lithium (included)
- Battery Life: 2 years *estimated
- Security Protocol: KeeLoq Hopping code
- Range in open space: 200/300 m
- Operating Temperature: -20° C to +80° C
- Overall dimensions: 105 x 70 x 23.5 mm
- Weight: 100g (3.5 oz)
Specifications
- Model: TRAKEYFREE2-W
- Also known as: 433TRAKEYFREE2-W
- Manufacturer: Transmitter Solutions
- Type: Wall mounted capacitive touch transmitter, single channel
- Frequency: 433.92 MHz (AM/ASK modulation)
- Security protocol: KeeLoq hopping code
- Range in open space: 200-300 m
- Battery: ER14505 lithium (included); estimated life 2 years
- Operating temperature: -20°C to 80°C
- Dimensions: 105 x 70 x 23.5 mm
- Weight: 100 g (3.5 oz)
- Environmental rating: IP55, indoor or outdoor
- Mounting: Surface/wall mount
- Finish: White
- Compatible with: 433 MHz long range receivers (sold separately)
- UPC: 3561324142137
