433Mhz Monarch 1 Button Transmitter, Key Chain Style

Product Overview

The Transmitter Solutions - Monarch transmitter is a key chain style mini transmitter operating at 433.92 MHz. It has been designed for the control of automatic closing systems and anti-burglar systems, thanks to its very high security coding system (KeeLoq Hopping code). The code sent by the transmitter changes at each activation, avoiding any scanning and copying risk. A special algorithm allows to keep synchronized transmitter and receiver.

Each transmitter is individually numbered and can be used with any receiver capable of receiving a 26 bit input. The supplied CR2016 lithium batteries have a shelf life of about 6 months before installation, so replace them if the transmitter has been in storage longer. The product fully complies with Part 15 of FCC Regulations and the European Directives 99/05/CE, 89/336/CEE, 73/23/CEE.

Specifications

• Model: 433TSPW1K
• Also known as: MON433TSPW1K-C
• Manufacturer: Transmitter Solutions
• Type: Key chain style transmitter (Monarch), 1 button
• Operating frequency: 433.92 MHz
• Security code: KeeLoq hopping code
• Code combinations: 2^64 (about 18.4 quintillion)
• Battery: 2 x 3 V lithium CR2016
• Battery life: 18-24 months
• Operating temperature: -20°F to 131°F (-29°C to 55°C)
• Dimensions: 2.4 inches x 1.4 inches x 0.51 inches (61 x 36 x 13 mm)
• Weight: 0.49 oz (14 g)
• Compliance: FCC Part 15
• Warranty: 2 Year
