Securitron SP-1 Touch Sense Exit Plate
Overview
Securitron SP-1 Touch Sense Request to Exit Plate
Touch Sense Technology in a Wall-Mount Request to Exit Plate
The SP-1 uses patented touch sensing technology to create a push plate with no moving parts. For indoor use only, the unit is oversized so that it can be mounted over a single gang cutout. A three part vinyl decal is included and a red LED is incorporated into the backbox.
Features:
• DPST 2 Amp relay
• Internal 0-25 second timer
• Red LED on the backbox
• Includes a three-part vinyl "Touch to Exit" decal
Product Details
Securitron SP-1 Touch Sense Exit Plate
Product Overview
The SP-1 uses patented touch sensing technology to create a push plate with no moving parts. For indoor use only, the unit is oversized so that it can be mounted over a single gang cutout. A three part vinyl decal is included and a red LED is incorporated into the backbox.
Product Features
- DPST 2amp rated relay
- Internal 0-25 second timer
- Built-in redundant button
- MagnaCare® lifetime replacement, no fault warranty
Specification Data
- Current Draw: 40mA at rest; 25mA releasing
- Voltage: 12 or 24VDC
- Operating Temperature: +32 to +110F [0 to +43C]
- Shipping Weight: 1.5 lbs.
Models
- SP-1 Touch Sensor Plate
- SP-1L Label Touch Plate [SP-1]
- SP-1LH Label Touch Plate [SP-1] - Handicap Decal
