iEXDa Electronic Exit Delay by Securitron, 1200lbs **DISCONTINUED**
Overview
iEXDa helps prevent peril to persons/patients and property loss/theft for businesses. Applications include dementia wards, hospitals, dormitories, airports, child care facilities and retail or warehouse environments. Installation requires no alteration or replacement of existing fire-rated or non-fire-rated latching hardware.
*Requires an external panic device to initiate alarm activation
Features:
- 1200lbs holding force Magnalock
- Compact 12-1/2 inch length can be used with most door closers
- 15 or 30 second delay times - user selectable
- External reset
- BondSTAT magnetic bond sensor and integrated door position switch standard
- Bright LEDs indicate unit status
- Automatic dual voltage - no field adjustment required
- Indoor use only
- UL Listed
Product Details
iEXDa Integrated Electronic Exit Delay, 1200lbs
Product Overview
iEXDa helps prevent peril to persons/patients and property loss/theft for businesses. Applications include dementia wards, hospitals, dormitories, airports, child care facilities and retail or warehouse environments. Installation requires no alteration or replacement of existing fire-rated or non-fire-rated latching hardware. False triggering is eliminated by up to 1 inch of authorized door movement. The iEXD version allows alarm initiation via an external panic device.
iMXDa helps prevent peril to persons/patients and property loss/theft for businesses. Applications include dementia wards, hospitals, dormitories, airports, child care facilities and retail or warehouse environments. Installation requires no alteration or replacement of existing fire-rated or non-fire-rated latching hardware. False triggering is eliminated by up to 1 inch of authorized door movement.
Specification Data
- Holding Force: 1200 lbs. [544 kg]
- Current Draw and Voltage: 370mA max at 12VDC; 270mA max at 24VDC
- Operating Temperature: +32 to +104F [0 to +40C]
- Shipping Weight: 15 lbs.
Product Features
- 1200 lbs. holding force Magnalock
- New shorter 12.5 inch overall length will fit most any door with a closer installed Now with automatic dual voltage - no field adjustment required
- New bracket-mounted design improves strength and installation time
- Microprocessor monitored BondSTAT magnetic bond sensor (MBS) and integrated door position switch (DPS) standard
- Reverse action plunger allows for adjustable alarm initiate gap from 1/8 inch [3.2mm] to 1 inch [25mm]
- Bright LEDs indicate unit status from the secure side of the door
- DIP switch selectable options:
- Nuisance alarm times - 0 to 3 seconds
- Irrevocable delay times - 15 or 30 seconds - user selectable
- External bypass delay times - 0, 5, 10 or 15 seconds
- Post alarm reminder - user selectable
- Bypass expiration alarm - user selectable
- Manual relock or delayed automatic relock (BOCA) - user selectable
- External alarm relay isolated dry contact (1A at 24VDC)
- External reset
- iEXD version allows alarm initiation via an external panic device
- Indoor use only
- UL Listed
- MagnaCare® lifetime replacement, no fault warranty
Models
- iEXDa Integrated Delay Egress External Initiate
- iMXDa Integrated Motion Exit Delay System
- iMXDa-CA Integrated Motion Exit Delay System - California*
- iMXDa-CH Integrated Motion Exit Delay System - Chicago
- iMXDa-H iMXDa for HUGS Infant Protection System
Certifications and Listings
- UL294
- ULC-S533 2008
- UL/cUL FWAX.SA6635
- UL Certificate of Compliance (CoC)
- FWAX2.SA6635 /FWAX8.SA6635
- CSFM 3774-0923:0105
- CAN/ULC-S533 Listed
- ANSI/UL 294 Listed
- NFPA 101
- CSFM - California State Fire Marshal Approved (IMXDA-CA only)
