Trilogy Networx, AL-IM3-80211 Hardwire/Wireless Gateway, Gen3

Product Overview

The AL-IM3-80211 "Version 3" Gateways (notice the "3" in the "IM3" model name) are the next generation of Networx "Wireless / Wired" Gateways used within the Trilogy Networx wireless system. The AL-IM3-80211 is the newest and most versatile Trilogy Networx Gateway yet.

The objective with all Gateways is to allow DL-Windows to "Discover" the Gateway through the customer's network. For this Discovery process to work, both the Gateway and DLWindows must be connected to the same customer network. The Gateway's network connection can be wired (through an RJ-45 Ethernet network cable) or wireless (through Wi-Fi).

ALL methods previously used with Version 1 and 2 Gateways to make a wired or Wi-Fi connection to the customer's network can also be used with Version 3 Gateways. Version 3 Gateways are backwards-compatible, and CAN be mixed into an existing system that includes older Version 1 or Version 2 Gateways.

Version 3 Gateways also include the added ability to expand your system with up to seven (7) AL-IME2-EXP Expanders.

Note: AL-IME2-EXP Expanders cannot communicate with older "non-Version 2" Gateways.

IMPORTANT: DL-Windows Version 5.5.4 or later is required to support Version 3 Gateways and Expanders.

Features

• Hardwire/Wireless Gateway Interface Module
• Supports up to 63 Networx Locks
• Supports up to 7 Expanders (model AL-IME2-EXP)
• Two Antennas
• Range: Clear field range 500'
• Typical Indoor range: 75 feet to 175 feet
• Note, actual range varies with building construction.
• Ceiling or wall mountable

Technical Specifications

• Power - Provided by UL listed Class 2 Transformer
• Peak Supply Current: 650mA
• Input Voltage: 5 - 6VAC
• Operating Temperature: -20° C to 60° C (-4° F to 140° F)
• Storage Temperature: -40° C to 85° C (-40° F to 185° F)
• Enclosure Size: 4.5 inches H x 6.0 inches W x 1.94 inches D
• Weight: 0.5lbs

Model

• AL-IM3-80211 - Hardwire/Wireless Gateway, Gen3 *

* replaces AL-IM2-80211 second generation model and * replaces AL-IM-80211 first generation model

Interface / Protocol

• Network Interface: Ethernet 10Base-T or 100Base-TX (using RJ45 Jack)
• PROTOCOLS: TCP/IP, UDP/IP, DHCP
