Securitron RB-4 Relay Board

$99.20 $124.00

Overview

The relay board provides normally open (NO) or normally closed (NC) relays that can be interconnected.

Ideal for interlock installations or wherever a basic relay board is used to trigger action, shunt alarms or report status from an access control system

More Info +


Select Model (available for 12 or 24 VDC):

Qty

Product Details

Securitron, RB-4 Relay Board

Product Overview

The RB4 board mounts four double pole, double throw relays with connection points to the coils and contacts being implemented on screw terminals. The boards are furnished on Snap Trak mounting permitting their installation in a variety of situations. The relays provide 2amp contacts on each pole. The 12 volt version of the board uses relays that draw 13 mA each and the 24 volt version uses relays that draw 8 mA each. The relays operate on DC only but will accept +50%, -25% of nominal voltage. Pulsating DC (transformer + bridge rectifier) will operate the relays. According to the status of jumper wires, the relays may be operated with one side of their coils in common or they may be fully isolated from each other.

  • Securitron RB4 board is used for interlock installations and where a basic relay board is needed.
  • The RB4 board mounts four double pole, double throw relays with connection points to the coils and contacts being implemented on screw terminals.
  • The boards are furnished on Snap Trak mounting permitting their installation in a variety of situations. The relays provide 2amp contacts on each pole. The 12 volt version of the board uses relays that draw 13 mA each and the 24 volt version uses relays that draw 8 mA each.

Product Features

  • Adds relays for uses including shunting, interlocking and reporting
  • Individual coil connections - common negative or positive
  • Replaces socket mount relays
  • Mounts 4 DPDT relays with 2amp contacts
  • All dry contact connections are brought out on screw terminals
  • Relays have low current coils (13mA at 12VDC; 8mA at 24VDC)
  • Allows operation from most LED drive outputs

Specifications

  • Operating Temperature: -13 to +158F [-25 to +70C]

Models

  • RB-4-12 - Relay Board - 12VDC
  • RB-4-24 - Relay Board - 24VDC
Maglocks.com Rating
Best
Manufacturer
Securitron
Model Number
RB-4-12 and RB-4-24
Usage
Interior Use
