Folger Adam 310-4 Strike, Rim Exit, Fire Rated Grade 1

Product Overview

Industrial grade electric strikes that offer extra heavy duty durability and tamper resistance. The 310-4 is a 3 hour fire-rated, industrial electric strike designed for extreme heavy duty applications. The all stainless steel construction of this device makes it ideal for high abuse applications that would disable other electric strikes. The 310-4 has a unique 3/4" face plate with an integraded 1/4" base shim that can be removed in the field to accommodate rim exit devices with a 1/2" or 3/4" throw latchbolt.

Standard Features

• Tamper resistant, heavy-duty construction
• Constructed entirely of stainless steel for strength and corrosion resistance
• Static strength 1,500 lbs.
• Dynamic strength 70 ft-lbs.
• Endurance rating 500,000 cycles
• Integrated shim for quick customization of faceplate thickness (3/4” to 1/2”)
• Integrated ramps to better accommodate deadlatches
• Set screws for horizontal lockdown
• In-frame horizontal adjustability
• Wider faceplate (1-3/4”) for greater versatility
• Non-handed
• Fail Secure (standard)
• Plug-in connector
• Five year limited warranty

Specifications

• UL 10C, 3 hour fire-rated (fail secure only)
• CAN4-S104 (ULC-S104) fire door conformant
• UL1034, burglary-resistant listed
• ANSI/BHMA A156.31, Grade 1
• NFPA-252 fire door conformant
• ASTM-E152 fire door conformant

Electrical Specifications

• .51amps @ 12VDC continuous dutyM/li>
• .25amps @ 24VDC continuous duty

Model

• 310-4-12D
• 310-4-24D
• 310-4-F-12D (Fail Safe)
• 310-4-F-24D (Fail Safe)
• 310-4-12D-LCBMA
• 310-4-24D-LCBMA
• 310-4-F-12D-LCBMA (Fail Safe)
• 310-4-F-24D-LCBMA (Fail Safe)

Options

• LCBMA - Detects position of latchbolt in pocket

Certifications and Listings

• UL 10C, 3 hour fire-rated (fail secure only)
• CAN4-S104 (ULC-S104) fire door conformant
• UL1034, burglary-resistant listed
• UL 294 listed
• ANSI/BHMA A156.31, Grade 1
• NFPA-252 fire door conformant
• ASTM-E152 fire door conformant
