Alarm Controls SLP Door Control and Monitoring Station

$170.00 ~~$200.00~~

Overview

Features:

DESIGNED TO RELEASE OR SECURE AND MONITOR ONE ELECTRIC LOCK

ONE 1/2” RED LED OPERATES ON 12 OR 24 VOLTS AC OR DC

1-8 D.P.D.T. ILLUMINATED LATCHING PUSHBUTTON WITH HI-BRIGHTNESS BUILT-IN LED

SWITCH LED OPERATES ON 12 OR 24 VOLTS AC OR DC

SWITCH CONTACTS RATED 3 AMPS @ 35 VDC OR 120 VAC

COMPONENTS MOUNTED ON STANDARD SINGLE GANG ELECTRICAL WALLPLATE

SWITCH AND LED TERMINATED WITH COLORED LEADS

GREEN AND YELLOW LEDS ARE AVAILABLE

CUSTOM SWITCH LEGENDS ARE AVAILABLE

Features

DESIGNED TO RELEASE OR SECURE AND MONITOR ONE ELECTRIC LOCK
ONE 1/2” RED LED OPERATES ON 12 OR 24 VOLTS AC OR DC
1-8 D.P.D.T. ILLUMINATED LATCHING PUSHBUTTON WITH HI-BRIGHTNESS BUILT-IN LED
SWITCH LED OPERATES ON 12 OR 24 VOLTS AC OR DC
SWITCH CONTACTS RATED 3 AMPS @ 35 VDC OR 120 VAC
COMPONENTS MOUNTED ON STANDARD SINGLE GANG ELECTRICAL WALLPLATE
SWITCH AND LED TERMINATED WITH COLORED LEADS
GREEN AND YELLOW LEDS ARE AVAILABLE
CUSTOM SWITCH LEGENDS ARE AVAILABLE

Model

SLP-1L, SLP-1M
SLP-2L, SLP-2M
SLP-3L, SLP-3M
SLP-4L, SLP-4M
SLP-5L, SLP-5M
SLP-6L, SLP-6M
SLP-7L, SLP-7M
SLP-8L, SLP-8M

Also Known As

AC-SLP2M, HES-SLP2M, SLP2M

Manufacturer

Alarm Controls

Manufacturer Warranty

1 Year

Model Number

SLP-XX

Mount

Single Gang Double Gang Triple Gang Quad Gang

Operation Momentary Timer Maintained

Momentary

Power Requirements

24V/12V AC/DC

Type

Basic

UPC Code

604840625968
