RCI 3513 Series Small Cabinet Locks
$115.20
$144.00
Overview
The 3513 and 3513DM cabinet locks are designed for small enclosures where power is available. These compact surface-mounted electric locks are versatile for side or top mounting.
The RCI 3513DM adds an option for dual monitoring to the standard electromechanical RCI 3513 cabinet lock.
Product Details
RCI 3513 Series Small Cabinet Locks
Product Overview
The 3513 and 3513DM cabinet locks are designed for small enclosures where power is available. These compact surface-mounted electric locks are versatile for side or top mounting.
The RCI 3513DM adds an option for dual monitoring to the standard electromechanical RCI 3513 cabinet lock.
Product Features
- Surface-mounted compact electric lock
- Superior heavy-duty metal construction
- Versatile side or top mounting
- Low energy consumption
- Positioning of the solenoid determines lock mode
- Black finish
- 440lbs Holding Force
- Field-Selectable Fail-Safe and Fail-Secure
- Optional Dual Monitoring Model Available
- 3 Year Limited Warranty
Specification Data
- 3513 Electromechanical Cabinet Lock Dimensions: 1-3/16 inches W x 2-7/8 inches H x 1-1/8 inches D (30mm x 73mm x 29mm)
- 3513DM Electromechanical Cabinet Lock with Monitoring Dimensions: 1-3/16 inches W x 3-11/16 inches H x 1-1/4 inches D (30mm x 94mm x 32mm)
Voltage
- 200mA Field-Selectable 12/24VDC (Max at 12VDC, 100mA at 24VDC)
Models
- 3513 - Electromechanical Cabinet Lock
- 3513DM - Electromechanical Cabinet Lock, Dual Monitoring
Applications
- Small Interior Enclosures
- Filing Cabinets
- Drug Cabinets
- Jewelry Cases
- Showcases
- Key Cabinets
- Desk Drawers
- Cash Drawers
- Machine Access
- Vending Machines Covers
Also Known As
RUT1003513, RUT1003513DMB, RU-3513B, RCI-3513Manufacturer
RCIManufacturer Warranty
3 YearModel Number
3513 and 3513DMPower Requirements
24VDC/12VDCUPC Code
785943346520
2 Questions asked on RCI 3513 Series Small Cabinet Locks •
Q
Ricky Russell • 02/07/2022, 9:25:14 AM
Are the 3513 Locks, able to be setup for power to Unlock?
A
02/08/2022, 11:24:31 AM
Yes, the 3513 cabinet lock can be setup for Power to Unlock or Power to Lock. This change is easy to do by removing a few screws and rotating the solenoid assembly.
Q
Tara • 08/17/2023, 7:24:20 PM
I'm trying to secure a jewelry drawer from cleaning staff. What opens this lock? Key, phone, fob?
Thanks,
Tara
P.s. Is this the best option for what we are trying to do?
A
08/18/2023, 11:26:48 AM
The 3513 cabinet lock would require some method of unlock (PIN pad, Prox Card, Wireless remote, phone app, etc) and a low-voltage power supply. For further assistance with your project and to get started on a complete system quote, please give us a call direct at 1-866-500-5625
