Product Overview

The FPR-1000 finger print reader with Wiegand 26-Bit output accepts fingerprints and RFID EM proximity cards from a range of up to 3 inches.

With the built in lock output and Wiegand 26-bit output you can choose to connect it directly to an electronic lock or wire to an access control system.

Programming is done using the included handheld IR programmer and program manual to add/remove users. Each unit also includes a mounting bracket and security screw for a tamper resistant installation.

Product Features

Interfaces with Cobra ACP-T line of panels or operates as a stand-alone
Finger print & RFID EM card activation
Capable of Wiegand 26 bit standard signal output
Internal buzzer
LED color control input
Built in tamper switch
Made of tough metal construction
1000 Fingerprint Users
2000 RFID Card Users

Technical Specifications

User Capacity: 3000
Card type: EM4100 125 Khz, Cobra 26-bit
Reading distance: 3 inch max
Operating Temp: 14°F to 122°F
Voltage: 12VDC
Idle draw: 20mA
Operating draw: 80mA
Interface: Wiegand 26
Dimensions: 4-5/16 inches L x 2-7/8 inches W x 1-1/4 inches D

Also Known As:

FPR-1000, fingerprint door entry reader

Format:

26-bit Cobra

Manufacturer:

Cobra Controls

Manufacturer Warranty:

2 Year

Model Number:

FPR-1000

Operation Keypad:

Fingerprint/Prox card

Power Requirements:

12VDC

Log PDF

Datasheet PDF

Quickstart Guide PDF

1 Question asked on Cobra Controls FPR-1000 Biometric Reader **DISCONTINUED** • Ask a Question

Q John Gilmour • 11/08/2018, 10:59:59 AM Can this device be programmed using a laptop computer? Is there any data output/software for auditing?

A 12/03/2018, 11:47:09 AM FPR-1000 can only be programmed using the included IR remote. FPR-1000 does not include software for audit but does have a 26bit Wiegand output.
